Recessed Downlight
Indoor
Aluminium Recessed Downlight (Z003)Stainless Steel Recessed Downlight Fixed/Adjustable (Z003)Aluminium LED Recessed DownLight Adjustable (Z003)Aluminium LED Mini Spot Light (H002)
Aluminium Recessed Downlight (Round) – IP20 / IP65
-Black, White, Gold Mix- Aluminium Recessed Downlight (Round) – IP20 / IP65
-Black / White Mix- Aluminium Recessed Downlight (Round) – IP20 / IP65
Description
-
Aluminium housing with corrosion resistant powdercoat 3mm toughened glass diffuser
Cut out : Φ70-75mm
CE/SAA/IP20/IP65
CREE/Bridgelux COB: 3000K/4000K/6000K/CRI≥80/90
Beam Angle: 12°/24°/36°/60°
Input: 220-240Vac/WT:-20~+50° C
-
Aluminium housing with corrosion resistant powdercoat 3mm toughened glass diffuser
Cut out : Φ85-95mm
CE/SAA/IP20/IP65
CREE/Bridgelux COB: 3000K/4000K/6000K/CRI≥80/90
Beam Angle: 12°/24°/36°/60°
Input: 220-240Vac/WT:-20~+50° C
-
Aluminium housing with corrosion resistant powdercoat 3mm toughened glass diffuser
Cut out : Φ90-95mm
CE/SAA/IP20/IP65
CREE/Bridgelux COB: 3000K/4000K/6000K/CRI≥80/90
Beam Angle: 12°/24°/36°/60°
Input: 220-240Vac/WT:-20~+50° C
-
Aluminium housing with corrosion resistant powdercoat 3mm toughened glass diffuser
Cut out : Φ135-145mm
CE/SAA/IP20/IP65
CREE/Bridgelux COB: 3000K/4000K/6000K/CRI≥80/90
Beam Angle: 12°/24°/36°/60°
Input: 220-240Vac/WT:-20~+50° C
-
Aluminium housing with corrosion resistant powdercoat 3mm toughened glass diffuser
Cut out : Φ110-115mm
CE/SAA/IP20/IP65
CREE/Bridgelux COB: 3000K/4000K/6000K/CRI≥80/90
Beam Angle: 12°/24°/36°/60°
Input: 220-240Vac/WT:-20~+50° C
Specifications
Dimensions
Photometric
-Fixed- Stainless Steel Recessed Downlight (Round) – IP20 / IP65
-Adjustable- Stainless Steel Recessed Downlight (Round) – IP20 / IP65
Description
- Stainless Steel Housing
3mm t oughened glass diffuser
Cut out : Φ70-75mm
CE/SAA/IP20/IP65
CREE/Bridgelux COB: 3000K/4000K/6000K/CRI≥80/90
Beam Angle: 12°/24°/36°/60°
Input: 220-240Vac/WT:-20~+50° C
Specifications
Dimensions
Photometric
Aluminium Recessed Downlight (Adjustable) – IP20 / IP65
Description
- Aluminium housing with corrosion resistant powdercoat 3mm toughened glass diffuser
Cut out : Φ90-95mm
CE/SAA/IP20/IP65
CREE/Bridgelux COB: 3000K/4000K/6000K/CRI≥80/90
Beam Angle: 12°/24°/36°/60°
Input: 220-240Vac/WT:-20~+50° C
Specifications
Dimensions
Photometric
Aluminium Mini Spot Light (Round) – IP20
Description
Power: 1.5 W
Beam: 15, 27, 60 Degrees
Chip: OSRAM 3030
Material: Die-cast Aluminium
Cut Hole: 26mm
Power: 2.5 W
Beam: 15, 25, 50 Degrees
Chip: OSRAM 3030
Material: Die-cast Aluminium
Cut Hole: 35mm
Power: 4 W
Beam: 15, 25, 45 Degrees
Chip: OSRAM 3030
Material: Die-cast Aluminium
Cut Hole: 50mm
Power: 8 W
Beam: 20 and 40 Degrees
Chip: COB CREE 1304
Material: Die-cast Aluminium
Cut Hole: 60mm
Power: 12 W
Beam: 15, 24, 34 Degrees
Chip: COB CREE 1507
Material: Die-cast Aluminium
Cut Hole: 70mm
Specifications
Dimensions
Photometric
View Catalogue(s) Here:
